9 - Camshaft adjustment valve 1 -N205-
❑ Component location ⇒ page 12
10 - Throttle valve control module -J338-
❑ After replacement, adapt in operating mode “Guided Fault-Finding” in “Adapting throttle valve control
module”
11 - Evaporative emission (EVAP) canister purge solenoid valve -N80-
12 - Intake Air Temperature (IAT) sensor -G42- / Manifold Absolute Pressure (MAP) sensor -G71-
❑ Component location ⇒ page 13
13 - Intake Manifold Runner Control (IMRC) valve -N316-
Component location ⇒ page 13
14 - Knock sensor 1 -G61- 20 Nm
❑ Component location ⇒ page 14
❑ Connector location ⇒ page 12
15 - Intake Manifold Tuning (IMT) valve position sensor -G513-
❑ Component location ⇒ page 12
16 - Change over valve for intake manifold flap -N239-
❑ Component location ⇒ page 12
17 - Engine Coolant Temperature (ECT) sensor -G62-
❑ Component location ⇒ page 12
18 - Actuator for intake manifold change over
19 - Intake manifold runner position sensor -G336-
❑ Component location ⇒ page 14
❑ After replacing, adapt in “Guided Fault Finding” operating mode under “Adapting intake manifold runner
position sensor”
20 - Fuel injectors, cylinder bank 1
❑ Cylinder 1 fuel injector -N30-
❑ Cylinder 2 fuel injector -N31-
❑ Cylinder 3 fuel injector -N32-
❑ Removing and installing ⇒ page 35 .
21 - Camshaft Position (CMP) sensor -G40-
❑ Component location ⇒ page 12
22 - Ignition coils, cylinder bank 1
❑ Ignition coil 1 with power output stage -N70-
❑ Ignition coil 2 with power output stage -N127-
❑ Ignition coil 3 with power output stage -N291-
❑ Removing and installing ⇒ page 57 .
Engine Compartment, Left
Audi A6 2005 ➤
Fuel Injection and Ignition - Edition 03.2008
2. Description and Operation 7
