Audi RS 3 LMS DSG User Manual

19
Extra sensors
In case of adding extra sensors, they have to be connected to an expansion module.
This expansion module has to be connected through the data hub as shown in the
scheme 2.
Notes:
 Channel expansion module and sensors are available through AIM dealers, not Audi Sport.
 If for any reason it is necessary to send data acquisition files to Audi Sport, following data file
extensions must be sent: .drk, .gpk and .xrk.
Data acquisition
AIM-MXG channel list:
Channel name
Description
Unit
Recommended scale
P_TURBO
Boost pressure
bar
0 ... 3
T_ENG_AIR
Intake air temperature
°C
20 ... 75
T_ENG_OIL
Engine oil temperature
°C
80 ... 150
T_ENG_WATER
Engine coolant temperature
°C
70 ... 125
T_AIR
External air temperature
°C
12 ... 45
RPM_ENG
Engine speed
rpm
1000 … 7000
FLAG_BRAKE
Brake lights
on/off
0 … 2
P_BRK_FRONT
Front brake pressure
bar
0 … 100
P_BRK_REAR
Rear brake pressure
bar
0 … 100
BRK BALANCE
Brake balance
%
0 … 100
P_ENG_OIL
Engine oil pressure
bar
1,5 … 5
P_ENG_FUEL
Fuel low pressure
bar
0 … 7
FUEL_LEVEL
Fuel level
l
0 … 110
FUEL_CONS
Fuel consumed
l
0 … 110
S_FUEL
Fuel remaining time
min
0 … 120
N_FUEL
Fuel remaining laps
#
0 … 80
LAP_CONS
Fuel lap consumption
l /lap
0 … 3
POS_PEDAL
Gas pedal position
%
0 … 100
TIP_DOWN
Tip down
Sign
0 … 2
TIP_UP
Tip up
Sign
0 … 2
G_CH_Y
Lateral acceleration
G
-2,5 … 2,5
G_CH_X
Longitudinal acceleration
G
-1,6 … 1,6
W_CH
Yaw rate
°/s
-50 … 50
V_WHL_RL
RL wheel speed
km/h
0 … 260
V_WHL_RR
RR wheel speed
km/h
0 … 260
V_WHL_FL
FL wheel speed
km/h
0 … 260
V_WHL_FR
FR wheel speed
km/h
0 … 260
V_WHL_REF
ESP reference speed
km/h
0 … 260
V_STW_LIMIT
Pit limiter speed
km/h
20 … 100
V_STW_FCY
Full Course Yellow speed
km/h
20 … 100
A_STE
Steering angle
°
-200 … 200
FLAG_STW_OUT1
Steering wheel button state
#
0 … 8
FLAG_STW_OUT2
Steering wheel button state
#
0 … 8
FLAG_STW_OUT3
Steering wheel button state
#
0 … 8
FLAG_FBX_RELAY1
Fusebox relay 1 state
#
0 … 8
FLAG_FBX_RELAY2
Fusebox relay 2 state
#
0 … 8
FLAG_FBX_5
Fuse state 5
#
0 … 8
FLAG_FBX_4
Fuse state 4
#
0 … 8
FLAG_FBX_3
Fuse state 3
#
0 … 8
FLAG_FBX_2
Fuse state 2
#
0 … 8
FLAG_FBX_1
Fuse state 1
#
0 … 8
I_FBX_MAIN
Main current
A
10 … 40
I_FBX_TURNLIGHT
Turn light current
A
0 … 10
EXTERNAL
VOLTAGE
Battery Voltage
V
8 … 15
