25
* Long left push will scroll menu on the other side.
** “Auto” will adjust automatically the brightness. Else, use right / left touch to increase / decrease light
level.
*** “dot” mode will light on only one led on the bar graph. “bAr” mode will light on all leds beginning
from the left side up to the level point. Note that the last led matches with the Full value set.
Auxiliary connectors
The main car wiring loom is prepared with some auxiliary connectors to make easier the connection of
auxiliary devices.
Free connectors inside the cockpit
#1: Auxiliary power supply
This connector is placed in the driver cockpit above the central tunnel (front). It could be used for user
requirements such as connecting the TCR scrutineering logger.
