Audi RS 3 LMS DSG User Manual

5
Dimensions and weight
Dimensions
Measurements
Remarks
Overall length
4589 mm
Overall bodywork front width
1950 mm
Overall bodywork rear width
1950 mm
Wheel base
2665 mm
Over hang front splitter
874 mm
Over hang front bumper
844 mm
Over hang rear
954 mm
Over hang rear wing*
96 mm
From the wing to the bumper
Minimum ground clearance
-
80 mm according to TCR regulations
Weight
Measurements
Total weight in race conditions without fuel
1215 kg **
Car balance
59,5% front / 40,5% rear
Distribution weight/power
3,47 kg/hp
Notes:
* Measured from the rear bumper to the end of rear wing profile.
** The scrutineering dimensions and minimum weight are the ones on the Audi RS 3 LMS DSG Technical
Form.
Bodywork
Part number
Description
Material
01
Bonnet
Steel
02
Left / right front door
Steel
03
Left / right rear door
Steel
04
Roof
Steel
05
Boot lid
Steel
10
Roof hatch
Carbon
11
Bonnet opening
Carbon (painted)
12
Front splitter
Carbon
13
Fender air exit
Carbon (painted)
14
Front bumper
Fiberglass
15
Rear bumper
Fiberglass
16
Left / right side trim
Carbon + Kevlar
17
Left / right rear door extension
Carbon (painted)
18
Left / right rear fender extension
Carbon (painted)
19
Left / right front fender
Carbon (painted)
20
Diffuser
Carbon (painted)
