Audio Technica AT-LP120XBT-USB User Manual

8
Preparation for use
Installing/removing the dust cover
• The dust cover is designed to protect the product's sensitive
components when the product is not in use. It should remain off
while records are playing.
• Using the dust cover during play may result in record damage or
sound degradation.
• Always remove and replace the dust cover carefully.
Connecting the AC adapter
Finally, after all audio connections are made, attach the included
AC adapter to the product. Then connect the AC adapter's cord to a
convenient AC outlet.
Wireless/wired connection
You can connect to a speaker, etc. via Bluetooth technology or RCA
audio cable.
When using Bluetooth, refer to “Connecting via Bluetooth wireless
technology” on p.9.
When connecting with the RCA audio cable, refer to “Connecting to
audio source” on p.10.
• Volume adjustment cannot be performed if there is no volume
adjustment on the connected speakers, etc.
Wired connection example
Amp / speaker
Wireless connection example
Wireless headphones
or
Wireless active speaker

Audio Technica AT-LP120XBT-USB Specifications

General

Drive Method	Direct Drive
Motor	DC servo motor
Speeds	33-1/3 RPM, 45 RPM, 78 RPM
Bluetooth	Yes
USB Output	Yes
Phono Preamp	Yes
Cartridge	AT-VM95E
Signal-to-Noise Ratio	>50 dB
Bluetooth Version	5.0
Platter	Aluminum
Tonearm Type	S-shaped tonearm
Wow and Flutter	<0.2% WRMS
USB Function	A/D: 16 bit 44.1 kHz or 48 kHz USB selectable
Power Supply	100-240V, 50/60 Hz, 1.5A
Weight	8 kg
Bluetooth Output	SBC
Stylus	0.3 x 0.7 mil Elliptical Diamond Stylus
