Specifications
Turntable specifications
Type 2-Speed, fully automatic operation
Motor DC motor
Drive method Belt drive
Speeds 33-1/3 RPM, 45 RPM
Turntable platter Die-cast aluminium
Wow and flutter < 0.2 % WRMS (33 RPM) at 3 kHz
Signal-to-noise ratio > 60 dB
Outputs levels
“PHONO”
“LINE (MM)”
3.5 mV nominal at 1 kHz, 5 cm/sec
220 mV nominal at 1 kHz, 5 cm/sec
Phono Pre-amp gain (MM)
Phono Pre-amp gain (MC)
36 dB nominal, RIAA equalized
56 dB nominal, RIAA equalized
Tonearm specifications
Type Static balanced straight shaped w/soft
damping control
Effective length 221.5 mm
Overhang 19 mm
Maximum tracking error angle Less than 3°
Stylus pressure adjustment range 1 to 4 g
Applicable cartridge weight range
(including headshell)
14.5 to 20 g
Cartridge and headshell specifications
Cartridge Model AT91R
Cartridge Type VM Dual Magnet
Recommended load impedance 47,000 ohms
Output voltage 3.5 mV (mV at 1 kHz, 5 cm/sec)
Stylus 0.6 mil bonded conical
Cantilever Aluminum pipe
Tracking force range 1.5 to 2.5 g (standard 2.0 g)
Cartridge weight 5.0 g
Headshell model AT-HS3
Headshell weight 11.1 g
Headshell overhang adjustment 8 mm
General specifications
Power supply requirements 220 to 240 V / 50, 60 Hz
Power consumption 2 W
Dimensions 435 mm (17.13")×353 mm (13.90")×
128 mm (5.04")
(W×D×H)
Weight 5.2 kg (11.46 lbs)
Accessories included Rubber mat, Dust cover, Platter (with
drive belt), Counterweight, Headshell
(AT-HS3) with VM stereo cartridge
(AT91R), 45 RPM adapter, Power cable*
Replacement stylus (sold
separately)
ATN91R
Replacement headshell (sold
separately)
AT-HS3
Replacement belt (sold separately) AT-LP3 exclusive belt
*Use the correct power cable for the country you live in.
Specifications are subject to change without notice due to improvements.
