General| Drive Method | Belt Drive |
|---|---|
| Type | Fully Automatic |
| Speeds | 33-1/3 RPM, 45 RPM |
| USB Output | Yes |
| Replacement Stylus | ATN3600L |
| Platter | Aluminum |
| Motor | DC servo-controlled |
| Phono Pre-Amp Gain | 36 dB nominal, RIAA equalized |
| Phono Preamp | Built-in switchable phono preamp |
| Cartridge | AT3600L |
| Dimensions | 359.5 mm x 97.5 mm x 373.3 mm |
| Weight | 2.6 kg |
| Wow and Flutter | < 0.25% (WTD) @ 3 kHz |
| Signal-to-Noise Ratio | > 50 dB |
| Output Level | 150 mV nominal at 1 kHz, 5 cm/sec |
| Power Supply | 100 to 240 V, 50/60 Hz |
| Power Consumption | 1W |
| USB Function | A/D, D/A - 16-bit/44.1 kHz or 48 kHz USB selectable |
| Tonearm | Static balance tonearm |
| Stylus | 0.6 mil conical |
| Outputs | RCA, USB |
| USB ADC | 16-bit, 44.1/48 kHz sampling |
