Audio Technica AT2020USB-XP User Manual

50
Caution
• If the mute indicator lamp is blinking, the sample rate setting differs from that set in the "Output" or
"Input" tab on the Mac you are using. Match the sample rate settings.
• Automatic gain control is available only when the sampling frequency is 44.1 kHz, 48 kHz, 88.2 kHz, or
96 kHz. If the sampling frequency is set to a sampling frequency that cannot be used, the Automatic
gain control indicator lamp will blink three times and turn off (indicating an error). Set to a supported
sampling frequency.
• Noise-reduction is available only when the sampling frequency is 44.1 kHz or 48 kHz. If the sampling
frequency is set to a sampling frequency that cannot be used, the noise-reduction indicator lamp will
blink three times and the light turn off (indicating an error). Set to a supported sampling frequency.

Audio Technica AT2020USB-XP Specifications

General

Headphone out	Yes
Device interface	3.5 mm (1/8\
USB connector type	USB Type-C
Connectivity technology	Wired
Type	PC microphone
Bit rate	24 bit
Sample rate	192 kHz
Volume control	Rotary
Microphone frequency	20 - 20000 Hz
Microphone Total Harmonic Distortion (THD)	1 %
Output impedance	32 Ω
Cable length	2 m
Control type	Buttons, Rotary
Product color	Black
Windows operating systems supported	Windows 10, Windows 11
Cables included	USB Type-C to USB Type-A
Number of products included	1 pc(s)
Power source	USB
Input voltage	5 V

Weight and Dimensions

Height	142 mm
Diameter	52 mm
Microphone weight	375 g
