Audio Technica ATW-T3201 User Manual

8
How to insert batteries
ATW-T3201
1. Slide the battery cover latches down.
2. Open the battery cover while the latches are slid.
3. Insert the batteries according to the plus (+) and minus (-) marks
found inside the battery compartment.
ATW-T3202
1. Rotate the grip case of the battery compartment.
2. Open the battery cover.
• Put your finger on the hook of the battery cover and pull it to open the
battery cover.
3. Insert the batteries according to the plus (+) and minus (-) marks
found inside the battery compartment.

Audio Technica ATW-T3201 Specifications

General

Quantity	1
Form factor	Bodypack transmitter
Antenna type	Built-in
Display type	OLED
Product color	Black
Built-in display	Yes
Housing material	Metal
Operating frequency	60 MHz
Operating frequency type	Ultra High Frequency (UHF)
Battery type	AA
Battery voltage	1.5 V
Battery life (max)	9.5 h
Number of batteries supported	2

Weight and Dimensions

Depth	82 mm
Width	64 mm
Height	23 mm
Weight	102 g
