1. Speaker Terminals
CH1 CH2 CH3 CH4
Bridged Bridged
CH1 CH2 CH3 CH4
A4004J
A6004J
Speaker
A8000J
A16000J
These chrome plated connectors can accept from 16 to 8 gauge wire. Be careful to observe proper polarity when
connecting the cables
2. B - Terminal (Chassis ground)
R E M B A T T G N D
POWER
A2002J
A4002J
A8002J
A4004J
A6004J
A8000J
A16000J
To avoid unwanted ignition noise caused by ground loops, it is essential that the amplifier be grounded to a
clean, bare, metal surface of the vehicles chassis.
