MP-1xx SIP

MP-1xx SIP User’s Manual 210 Document #: LTRT-65404

C.3 Default RTP/RTCP/T.38 Port Allocation

The following table shows the Default RTP/RTCP/T.38 Port Allocation.

Table C-3: Default RTP/RTCP/T.38 Port Allocation

Channel Number RTP Port RTCP Port T.38 Port

1 4000 4001 4002

2 4010 4011 4012

3 4020 4021 4022

4 4030 4031 4032

5 4040 4041 4042

6 4050 4051 4052

7 4060 4061 4062

8 4070 4071 4072

9 4080 4081 4082

10 4090 4091 4092

11 4100 4101 4102

12 4110 4111 4112

13 4120 4121 4122

14 4130 4131 4132

15 4140 4141 4142

16 4150 4151 4152

17 4160 4161 4162

18 4170 4171 4172

19 4180 4181 4182

20 4190 4191 4192

21 4200 4201 4202

22 4210 4211 4212

23 4220 4221 4222

24 4230 4231 4232

Note: To configure the gateway to use the same port for both RTP and T.38

packets, set the parameter ‘T38UseRTPPort’ to 1.
