MP-1xx SIP
MP-1xx SIP User’s Manual 98 Document #: LTRT-65404
5.8.8.5 Caller ID Permissions
The Caller ID Permission table is used to enable or disable (per port) the Caller ID generation (for
FXS gateways) and detection (for FXO gateways). If a port isn’t configured, its Caller ID
generation / detection are determined according to the global parameter ‘EnableCallerID’
(described in Table
5-6).
To configure the Caller ID Permission Table, take these 5 steps:
1. Open the ‘Caller ID Permission’ screen (Protocol Management menu > Endpoint Settings
> Caller ID Permission option); the ‘Caller ID Permission ’ screen is displayed.
Figure
5-25: MP-1xx FXS Caller ID Permission Screen
2. In the ‘Caller ID’ field, select one of the following:
Enable – Enables Caller ID generation (FXS) or detection (FXO) for the specific port.
Disable – Caller ID generation (FXS) or detection (FXO) for the specific port is disabled.
Empty – Caller ID generation (FXS) or detection (FXO) for the specific port is determined
according to the parameter ‘EnableCallerID’ (described in Table 5-6).
3. Repeat step 2 for each port.
4. Click the Submit button to save your changes.
5. To save the changes so they are available after a power fail refer to Section
5.12 on page
139.
Table
5-24: Authentication ini File Parameter
Parameter Name in ini File Parameter Format
EnableCallerID_X
EnableCallerID_<Port> = <Caller ID>
Caller ID:
0 = Disabled (default).
1 = Enabled.
If not configured, use the global parameter ‘EnableCallerID’.
Note 1: The numbering of ports starts with 0.
Note 2: This parameter can appear up to eight times for MP-108, and up
to 24 times for MP-124.
