MP-1xx SIP User’s Manual 5. Configuring the MP-1xx
Version 4.4 65 March 2005
Table 5-6: Supplementary Services Parameters (continues on pages 64 to 65)
Parameter Description
Enable Caller ID
[EnableCallerID]
No [0] = Disable the Caller ID service (default).
Yes [1] = Enable the Caller ID service.
If the Caller ID service is enabled, then, for FXS gateways, calling number and Display
text are sent to gateway port.
For FXO gateways, the Caller ID signal is detected and is sent to IP in SIP INVITE
message (as "Display" element).
For information on the Caller ID table refer to Section
5.8.8.3 on page 95.
To disable/enable caller I generation per port, refer to Section 5.8.8.5 on page 98.
Caller ID Type
[CallerIDType]
Defines one of the following standards for detection (FXO) and generation (FXS) of
Caller ID signals.
Bellcore [0] (default).
ETSI [1].
NTT [2].
British [4]
DTMF ETSI [16]
Denmark [17]
India [18]
Brazil [19]
Note: The Caller ID signals are generated/detected between the first and the second
rings.
MWI Parameters
Enable MWI
[EnableMWI]
Enable MWI (message waiting indication).
Disable [0] = Disabled (default).
Enable [1] = MWI service is enabled.
This parameter is applicable only to FXS gateways.
Note: The MP-1xx only supports reception of MWI.
For detailed information on MWI, refer to Section
8.4.6 on page 156.
MWI Analog Lamp
[MWIAnalogLamp]
Disable [0] = Disable (default).
Enable [1] = Enable visual Message Waiting Indication, supplies line voltage of
approximately 100 VDC to activate the phone’s lamp.
This parameter is applicable only to FXS gateways.
MWI Display
[MWIDisplay]
Disable [0] = MWI information isn’t sent to display (default).
Enable [1] = MWI information is sent to display.
If enabled, the gateway generates an MWI FSK message that is displayed on the MWI
display.
This parameter is applicable only to FXS gateways.
Subscribe to MWI
[EnableMWISubscription]
Disable [0] = Disable MWI subscription (default).
Enable [1] = Enable subscription to MWI (to MWIServerIP address).
Note: Use the parameter ‘SubscriptionMode’ (described in Table
5-26 on page 101) to
determine whether the gateway subscribes separately per endpoint of for the entire
gateway.
MWI Server IP Address
[MWIServerIP]
MWI server IP address. If provided, the gateway subscribes to this IP address.
Can be configured as a numerical IP address or as a domain name. If not configured,
the Proxy IP address is used instead.
MWI Subscribe Expiration
Time
[MWIExpirationTime]
MWI subscription expiration time in seconds.
The default is 7200 seconds. The range is 10 to 72000.
MWI Subscribe Retry Time
[SubscribeRetryTime]
Subscription retry time in seconds.
The default is 120 seconds. The range is 10 to 7200.
Stutter Tone Duration
[StutterToneDuration]
Duration (in msec) of the played stutter dial tone that indicates waiting message(s).
The default is 2000 (2 seconds). The range is 1000 to 60000.
The Stutter tone is played (instead of a regular Dial tone) when a MWI is received. The
tone is composed of a ‘Confirmation tone’ that is played for ‘StutterToneDuration’
followed by a ‘Stutter tone’. Both tones are defined in the CPT file.
Note: This parameter is applicable only to FXS gateways.
For detailed information on Message Waiting Indication (MWI), refer to Section
8.4.6 on
page 156.
