Audiolab M-DAC Service Manual

ELECTRONIC PARTS LIST
M-DAC
21
M-DAC Electronic Bom--P2/5
No. LEVEL P/N PART NAME DESCRIPTION QTY UNIT LOCATION
47 2 088-1018420001R Main board PCBA
Main board PCBA(SMD components
assembled)
1PCS
48 3 002-0000011050R Resistor 0R 0603 1% 50V 2 PCS R346.R353.
49 3 002-0000032010R Resistor OR 1/8W 1% 8 PCS R14.R24.R46.R56.R79.R88.R110.R120
50 3 002-0000033050R Resistor 1206 0R 1/8W 5% 2 PCS R287.R290
51 3 002-1000011010R Resistor 10K 1% 0603 50V 29 PCS
R309.R313.R314.R316.R320.R322.R323
.R329.R330.R332.R338.R340.R344.R36
4.R369.R379.R386
52 3 002-1000032010R Resistor 10Ω 1/8W 1% 0805 4 PCS R20.R51.R84.R115
53 3 002-1001021010R Resistor RES 100 OHM 1/10W 1% 0603 28 PCS
R11.R12.R21.R44.R45.R52.R76.R77.R8
5.R108.R109.R116.R308.R319.R333.R3
39.R341.R345.R348.R349.R350.R351
54 3 002-1001032010R Resistor 100Ω 1/8W 1% 0805 4 PCS R19.R55.R83.R119
55 3 002-1001033010R Resistor 100R 1% SMD 0603 1 PCS R406
56 3 002-1002049010R Resistor 1K MELF 0204 1% 250V 1/4W 8 PCS R2.R5.R34.R37.R66.R69.R98.R101
57 3 002-1003032010R Resistor 10KΩ 1/8W 1% 0805 6 PCS R137.R138.R288.R289.R291.R292
58 3 002-1004021010R Resistor RES 100K OHM 1/10W 1% 0603 9 PCS
R307.R310.R311.R317.R318.R326.R327
.R342.R343.
59 3 002-1005021010R Resistor RES 1M OHM 1/10W 1% 0603 1 PCS R398
60 3 002-1100021010R Resistor 110R, 1%, 0603, 1/10W 1 PCS R377
61 3 002-1204032010R Resistor 0805 120K 1/8W 1% ROHS 4 PCS R25.R57.R89.R121
62 3 002-1301032010R Resistor 130R 1/8W 0805 1% 8 PCS R26.R28.R58.R60.R90.R92.R122.R124
63 3 002-1500021010R Resistor 15R, 1%, 0603, 1/10W 3 PCS R306.R334.R370
64 3 002-1500032010R Resistor 150R 1/8W 1% 0805 1 PCS R305
65 3 002-1502021010R Resistor RES 1.5K OHM 1/10W 1% 0603 1 PCS R382
66 3 002-1503032010HR Resistor
15K 1% 100PPM 0805 1/8W VISHAY
CRCW080515K00FKEA
2 PCS R300.R303
67 3 002-1801032010R Resistor 180Ω 1/8W 1% 0805 8 PCS R15.R16.R47.R48.R81.R82.R111.R112
68 3 002-1803071010R Resistor 18K 0603 1% 1/16W 1 PCS R380
69 3 002-2200009010R Resistor 22R MELF 0204 1% 1/2W 8 PCS R27.R29.R59.R61.R91.R93.R123.R125.
70 3 002-2200021010R Resistor 22R 0603 1/10W 1% 1 PCS R408
71 3 002-2200032010R Resistor 22Ω 1/8W 1% 0805 1 PCS R304
72 3 002-2201021010R Resistor 220R 0603 1/10W 1% 1 PCS R376
73 3 002-2201032010R Resistor 220Ω 1/8W 1% 0805 3 PCS R299.R302.R355
74 3 002-2202021010R Resistor RES 2.2K OHM 1/10W 1% 0603 6 PCS R315.R321.R324.R325.R331.R387
75 3 002-2203032010R Resistor 22K 1/8W 1% 0805 10 PCS
R10.R22.R42.R53.R74.R86.R106.R117.
R356.R360
76 3 002-2209049010R Resistor 220R MELF 0204 1% 1/2W 16 PCS
R1.R4.R7.R8.R33.R36.R38.R40.R65.R6
8.R71.R72.R97.R100.R103.R104.
77 3 002-2261032010R Resistor 226R, 1%, 0805, 1/8W 1 PCS R365
78 3 002-2700061010R Resistor 27R, 1%, 0603, 1/10W 4 PCS R312.R328.R381.R383
79 3 002-2702032010R Resistor 2.7KΩ 1/8W 1% 0805 4 PCS R130.R132.R134.R136.
80 3 002-3092061010R Resistor 3.09K, 1%, 0603, 1/10W 1 PCS R384
81 3 002-3300011010QR Resistor 33R 1/16W 1% 1 PCS R335
82 3 002-3301032010R Resistor 330Ω 1/8W 1% 0805 1 PCS R301
83 3 002-3901032010R Resistor 390Ω 1/8W 1% 0805 1 PCS R366
84 3 002-4700021010R Resistor 47R 0603 1/10W 1% 3 PCS R336.R337.R375
85 3 002-4700059010R Resistor 47R MELF 0204 1% 1/2W 8 PCS R3.R6.R35.R39.R67.R70.R99.R102
86 3 002-4701021010R Resistor 470R 0603 1/10W 1% 1 PCS R385
87 3 002-4701032010R Resistor 470Ω 1/8W 1% 0805 4 PCS R129.R131.R133.R135
88 3 002-4702021010R Resistor RES 4.7K OHM 1/10W 1% 0603 6 PCS R399.R402.R403.R405.R412.R418
89 3 002-4703032010R Resistor 47KΩ 1/8W 1% 0805 2 PCS R358.R362
90 3 002-4709049010R Resistor 4R7 MELF 0204 1% 250V 1/4W 12 PCS
R30.R31.R32.R62.R63.R64.R94.R95.R9
6.R126.R127..R128
91 3 002-5101032010R Resistor 510Ω 1/8W 1% 0805 4 PCS R18.R43.R75.R107
92 3 002-5602032010R Resistor 5.6KΩ 1/8W 1% 0805 2 PCS R359.R363
93 3 002-6800032010R Resistor 68R 1/8W 1% 4 PCS R23.R54.R87.R118
94 3 002-6802032010R Resistor 6.8KΩ 1/8W 1% 0805 6 PCS R13.R50.R78.R114.R357.R361
95 3 002-7500021010R Resistor 75R 1/10W 0603 1% 4 PCS R367.R368.R371.R372
96 3 002-8200032010R Resistor SMD0805 82R 1% 4 PCS R9.R41.R73.R105
97 3 003-1000080001R Resistor 100R 1/16W 1% 0603 8pin 1 PCS RA2
98 3 003-2210000005R Resistor 8P 22R 63MW 1206 5% 3.2*1.6MM 1 PCS RA1
99 3 007-1000001060R Capacitor 10PF/50V NPO 0603K 3 PCS C300,C478,C486
100 3 007-1000061060R Capacitor 10NF 50V X7R 0603 1/16W 10% 13 PCS
C302,C333,C348,C362,C366,C404,C429,
C434,C444,C448,C450,C452,C501
101 3 007-1000072060R Capacitor 10nF, 200V, 0805, X7R, 20% 2 PCS C503,C504
102 3 007-1000074010R Capacitor
100uF/6.3V 1210 X5R ±20%
GRM32ER60J107M MURATA
3 PCS C481.C488.C489.
103 3 007-1001031061R Capacitor 0603 100P/50V 5% MURATA 3 PCS C467.C512.C535
104 3 007-1001051060R Capacitor 100NF 0603 10% Murata 25V 138 PCS
C140-
C152,C299,C309,C310,C328,C329,C330,
C335-C341,C343,C344,C345,C349-
C360,C364,C367-C389
