Audiolab M-DAC Service Manual

ELECTRONIC PARTS LIST
M-DAC
152 3 056-8124551194R FPC Connector
SMD 24pin PH=1mm Vertical ZIF FFC
Connector
1 PCS CN2
153 3 067-7700099112R Diode BAV99 DUAL SOT-23 Philips/nxp 20 PCS
D1---
D12,D20.D25.D28.D29.D30.D31.D32.D33
154 3 067-7700316119R Diode BAS316 SOD323 PHILIPS 2 PCS D36.D37
155 1 088-1018424000R MDAC Front PCBA MDAC Front PCBA 1 PCS
156 2 006-1014080733R Electrolytic Capacitor
100uF 16V 20% D8*7MM SXJseries Lelon
105℃
1 PCS C5
157 2 006-1024080803R Electrolytic Capacitor 1000uF 4V OCRZ series 8*8 20% 105℃Lelon 3 PCS C1.C2.C3
158 2 006-4704080743R Electrolytic Capacitor
47uF 25V 20% D8*7MM SXJseries Lelon 105
℃
1 PCS C4
159 2 020-0002227134R Encoder + Push Switch
EC162101E1B-HA1-016 L=20MM φ6mm
R/T200
～
450gf
1PCS SW5
21
M-DAC Electronic Bom--P3/5
No. LEVEL P/N PART NAME DESCRIPTION QTY UNIT LOCATION
105 3 007-1001052060QR Capacitor 100PF50V 5% NPO 0805 4 PCS C297.C298.C532.C533
106 3 007-1002051063R Capacitor 1nF 0603 50v 5% COG 3 PCS C306.C307.C511
107 3 007-1004052060R Capacitor 100nF 50V 5% 0805 22 PCS
C284---
C296,C390,C391,C394,C395,C396,C454
,C455,C456,C457
108 3 007-1005061022R Capacitor 1U 10V 0306 10% (LWK107B7105KA-T) 17 PCS
C311.C312.C313.C314.C315.C316.C317
.C318.C319.C320.C321.C322.C323.C32
4.C325.C326.C327
109 3 007-1500001060R Capacitor 15PF/50V NPO 0603K 1 PCS C303
110 3 007-2200031061R Capacitor 0603 22P/50V 5% NPO 6 PCS C331.C431.C436.C446.C506.C507
111 3 007-2206052010R Capacitor 0805 22U/6.3V X5R 20% 6 PCS C301.C469.C483.C484.C487.C502
112 3 007-3009061060R Capacitor 3P 50V 10% 0603 (EZJZ1V500AA) 3 PCS ESD1.ESD2.ESD3
113 3 007-4700051060R Capacitor 47PF/50V 0603 5% 6 PCS C470.C473--C477
114 3 007-4705051010R Capacitor 0603 4.7U/6.3V 5% MURATA 33 PCS
C308.C332.C334.C342.C346.C347.C361
.C363.C365.C403.C405.C407.C415.C41
7.C419.C420.C423.C428.C433.
115 3 007-4708051061R Capacitor 4.7pF, 50V, 0603, NPO, 5% 2 PCS C305.C472
116 3 007-8209051063R Capacitor 8.2pF, 50V, 0603, COG, 5% 1 PCS C304
117 3 017-0211000000R IC 74VHC393MTC TSSOP14 Fairchild 1 PCS U27
118 3 017-0470000000R IC
WM8805GEDS SSOP-28 Wolfson
Micorelectronics
1 PCS U22
119 3 017-0480000000R IC NC7SZ18P6X SC70-6 Fairchild 1 PCS U29
120 3 017-1083000000R IC TC74VHC595FT TSSOP16 Toshiba 1 PCS U32
121 3 017-1089000000R IC NC7SZ157P6X SC70-6 Fairchild 2 PCS U26.U28.
122 3 017-1091000000R IC NE5532D SOIC-8 TI 3 PCS U4.U5.U6
123 3 017-1092000000R IC BC847BS SOT-363 Philips 24 PCS
Q2.Q4.Q6.Q8.Q9.Q12.Q18.Q20.Q22.Q2
4.Q26.Q28.Q34.Q36.Q39.Q40.Q41.Q44.
Q50.Q52.Q55.Q56.Q57.Q60
124 3 017-1093000000R IC BC857BS SOT-363 Philips 20 PCS
Q3.Q5.Q7.Q10.Q.11.Q19.Q21.Q23.Q25.
Q27.Q35.Q37.Q38.Q42.Q43.Q51.Q53.Q
54.Q58.Q59
125 3 017-1126000000R IC ZHCS400 SOD323 ZETEX 9 PCS
D19.D21.D22.D23.D24.D26.D27.D34.D3
5
126 3 017-1250000000R IC NC7SZ74K8X US8 fairchild 7 PCS U7.U8.U9.U15.U17.U19.U24
127 3 017-1251000000R IC NC7SZ04P5 SC70-5 FAIRCHILD 4 PCS U11.U12.U13.U25
128 3 017-1252000000R IC NC7SZ86P5X SC70-5 FAIRCHILD 1 PCS U10
129 3 017-1253000000R IC NC7WZ04P6X SC70-6 FAIRCHILD 1 PCS U2
130 3 017-1254000000R IC TAS1020B TQFP48 TI 1 PCS U31
131 3 017-1264000000R IC LM339PWR，TSSOP14 TI 1 PCS U21
132 3 017-1267000000R IC AT24C64CN-SH-T SO-8 ATMEL 1 PCS U23.
133 3 017-1292000000R IC ES9018 QFP 64 ESS Technlogies 1 PCS U1
134 3 017-1295000000R IC LM1117MPX-ADJ SOT-223 N03A NS 1 PCS U20
135 3 017-1391000000R IC STC809S SOT23 STC Micro 1 PCS U30
136 3 017-8160000000R IC NE5534D SO-8 W=3.9MM TI 4 PCS U3.U14.U16.U18
137 3 018-0002222227QR Transistor MMBT2222A NPN SMD SOT-23 3 PCS Q140.Q141.Q142
138 3 018-1080617227R Transistor FMMT617 SOT23 15V 3A 625mW ZETEX 7 PCS
Q133.Q134.Q135.Q136.Q137.Q138.Q13
9
139 3 018-1400846227R Transistor BC846 BLT1 SOT-23 PHILIPS 7 PCS Q14.Q29.Q46.Q61.Q145.Q148.Q152
140 3 018-1400856227R Transistor BC856 BLT1 SOT-23 6 PCS Q13.Q30.Q45.Q62.Q143.Q144
141 3 018-1500520227R Transistor BFR520 SOT23 PHILIPS 2 PCS Q131.Q132
142 3 018-4302907227AR Transistor MMBT2907ALT1G SOT-23 ON 2 PCS Q149.Q153
143 3 018-4500690224R Transistor FZT690B SOT-223 Zetex 4 PCS Q16.Q31.Q48.Q63
144 3 018-4500790224R Transistor FZT790A SOT-223 Zetex 4 PCS Q15.Q32.Q47.Q64
145 3 018-7203422227R MOSFET AO3422 Nch SOT-23 Alpha & Omega 1 PCS Q158
146 3 018-9800389236R JFET LSK389-C-SOIC-8 SOIC-A Linear Systems 4 PCS Q1.Q17.Q33.Q49
147 3 022-1009044385R SMD Transformer
ER-9.5 Screened Digital Isolation
Transformer
2 PCS T1 T2
148 3 027-3383022000R Inductor 330nH Wire Wound 0805 5% Inductor 1 PCS L2
149 3 027-4793022000R Inductor 4.7uH Wire Wound 0805 5% Inductor 1 PCS L1
150 3 035-1003062051R Inductor 1000ohm/100MHz 0805 BLM21BD102SN1D 19 PCS L3-L21
151 3 053-1048410000R
MDAC/QDAC Main
board PCB Rev0.3
Class 3 PCB 4 Layer FR4 1.6MM 1oZ 211.7 x
206.9mm
1PCS
