Audiolab M-DAC Service Manual

M-DAC
208 3 002-1503011010R Resistor RC03K153JT 2 PCS R15.R19
209 3 002-2203021010R Resistor RES 22K OHM 1/10W 1% 0603 4 PCS R9.R13.R17.R20
210 3 002-4703021010R Resistor 0603 47K1/8W1% 2 PCS R10.R18
211 3 007-1000072060R Capacitor 10nF, 200V, 0805, X7R, 20% 22 PCS
C15.C16.C17.C18.C20.C21.C23.C24.C2
5.C27.C28.C29.C31.C32.C33.C34.C36.C
38.C39.C40.C71.C72
212 3 007-1001052060QR Capacitor 100PF50V 5% NPO 0805 1 PCS C19
213 3 007-1004052060R Capacitor 100nF 50V 5% 0805 6 PCS C22.C26.C30.C35.C37.C41
214 3 018-1400846227R Transistor BC846 BLT1 SOT-23 PHILIPS 1 PCS Q7
215 3 018-1400856227R Transistor BC856 BLT1 SOT-23 2 PCS Q2.Q5
216 3 018-5600070227R Transistor BAV70LT1G SOT-23 ON 2 PCS D9.D10
217 3 018-7203404227R MOSFET AO3404A Nch SOT-23 Alpha & Omega 2 PCS Q1.Q4
218 3 018-7203407227R MOSFET AO3407A Pch SOT-23 Alpha & Omega 2 PCS Q3.Q6
219 3 053-1048410004R
MDAC/QDAC PUS PCB
Rev0.3
Class 3 PCB 2Layer FR4 1.6MM 2oZ 198.4x
47mm
1PCS
220 3 067-2200002103R Doide
S2J Silicon Rectifier Diode 2A 600V，SMA
(D0-214)
11 PCS
D1.D2.D3.D4.D5.D6.D7.D8.D11.D12.D13
.
ELECTRONIC PARTS LIST
23
M-DAC Electronic BomE- -P4/5
No. LEVEL P/N PART NAME DESCRIPTION QTY UNIT LOCATION
160 2 026-0000003000R Light Sensor AT405-ALS-T2 PH=5MM GOODTAKE 1 PCS U10
161 2 030-7324000000R OLED
VG-2864ASWDT09 128x64Dot 2.7 WISE
CHIP
1PCS
162 2 039-3000000000R Tact Switch TC-17XA 7.8*7.8*5 4 PCS SW1.SW2.SW3.SW4
163 2 044-6570000000R Connector 6PIN sh-56-01 PH=2.54MM 13.2*18MM 1 PCS CN3
164 2 044-6590000000R IR PAD 11*10*9.6 RCEB-8 1 PCS
165 2 052-2200000000R IR receiver KS1838 1 PCS U11
166 2 223-0500120803R Plastic Post
LEDK-8（KangYang）、NYLON66（UL）
94V-2
1 PCS Light Sensor+FRONT PCB
167 2 277-0120000001R Plastic Post
RCEB-7（KangYang） NYLON66（UL）94V-
2
1 PCS IR+FRONT PCB
168 2 088-1018424001R MDAC Front PCBA
MDAC Front PCBA(SMD components
assembled)
1PCS
169 3 002-0000011050R Resistor 0R 0603 5% 50V 1 PCS R17
170 3 002-1000011010R Resistor 10K 1% 0603 50V 10 PCS
R3.R7.R14.R15.R16.R26.R31.R32.R33.
R34.
171 3 002-1001021010R Resistor RES 100 OHM 1/10W 1% 0603 4 PCS R1.R11.R20.R21
172 3 002-1002021010R Resistor RES 1K OHM 1/10W 1% 0603 1 PCS R4
173 3 002-1004021010R Resistor RES 100K OHM 1/10W 1% 0603 2 PCS R2 R5
174 3 002-1203021010R Resistor RES 12K OHM 1/10W 1% 0603 1 PCS R6
175 3 002-1500021010R Resistor 15R, 1%, 0603, 1/10W 1 PCS R12
176 3 002-9103021010R Resistor 910K 0603 1/10W 1% 1 PCS R13
177 3 003-1000080001R Resistor 100R 1/16W 1% 0603 8pin 7 PCS RA1.RA2.RA3.RA4.RA5.RA6.RA7
178 3 007-1000001060R Capacitor 10PF/50V NPO 0603K 1 PCS C7.
179 3 007-1000061060R Capacitor 10NF 50V X7R 0603 1/16W 10% 3 PCS C24.C25.C30
180 3 007-1000072060R Capacitor 10nF, 200V, 0805, X7R, 20% 8 PCS C67.C68.C69.C70.C71.C72.C73.C74
181 3 007-1001031061R Capacitor 0603 100P/50V 5% MURATA 1 PCS C6
182 3 007-1001051060R Capacitor 100NF 0603 10% Murata 25V(20100830 21 PCS
C15.C16.C17.C18.C19.C20.C21.C27.C3
3.C34.C35.C36.C37.C39.C40.C41.C42.C
43.C48.C54.C55
183 3 007-1002051063R Capacitor 1nF 0603 50v 5% COG 5 PCS C53.C56.C57.C58.C59
184 3 007-1006072034R Capacitor 10uF 16V 20% X5R 0805 2 PCS C28.C29
185 3 007-2200031061R Capacitor 0603 22P/50V 5% NPO 8 PCS C9.C10.C11.C12.C13.C44.C45.C46.
186 3 007-2206052010R Capacitor 0805 22U/6.3V X5R 20% 5 PCS C14.C23.C26.C31.C32
187 3 007-3001001060R Capacitor 33PF/50V NPO 0603K 1 PCS C22
188 3 017-0170000000-1R IC PIC24FJ64GB106-I/PT TQFP64 Microchip 1 PCS U1
189 3 017-0211300000R IC
LP2951 SO8 ADJ 100mA ON(CDR2G)
Fairchild(CM)
1 PCS U6
190 3 017-0480000000R IC NC7SZ18P6X SC70-6 Fairchild 1 PCS U4
191 3 017-1089000000R IC NC7SZ157P6X SC70-6 Fairchild 1 PCS U5
192 3 017-1405000000R IC WM8804GEDS SSOP-20 Wolfson 1 PCS U2
193 3 035-1003062051R Inductor 1000ohm/100MHz 0805 BLM21BD102SN1D 5 PCS L1.L2.L3.L4.L5
194 3 053-1048410048R
MDAC/QDAC Front PCB
Rev0.2
Class 3 PCB 4 Layer FR4 1.6MM 1oZ 216.5
x40mm
1PCS
195 3 056-0230552190R FPC Connector
SMD 30pin PH=0.5mm Parallel ZIF FFC
Connector 1226-30-02
1 PCS CN2
196 3 056-8124551194R FPC Connector
SMD 24pin PH=1mm Vertical ZIF FFC
Connector
1 PCS CN1
197 3 067-7700316119R Diode BAS316 SOD323 PHILIPS 1 PCS D1
198 1 088-1018420400R MDAC PSU PCBA MDAC PSU PCBA 1 PCS
199 2 349-1006000011R Glounding piece PCB-2 2 PCS MH1
，
MH2
200 2 044-6550000000R S-video 9pin DIN-912A chunsheng 1 PCS CN1
201 2 041-1376000000QR SWITCH SWITCH MAINS２P SDDSA 3289A 1 PCS SW1
202 2 006-4724183503R Electrolytic Capacitor 4700u/25V 20% Lelon RXY 18*35mm 105℃ 5 PCS C1.C2.C3.C4.C5
203 2 088-1018420401R MDAC PSU PCBA
MDAC PSU PCBA(SMD components
assembled)
1PCS
204 3 055-0310030100R 10P Cable 2.54MM L=250MM 1007 24AWG 1 PCS
205 3 002-1000011010R Resistor 10K 1% 0603 50V 7 PCS R12.R14.R21.R23.R24.R25.R26
206 3 002-1001032010R Resistor 100Ω 1/8W 1% 0805 12 PCS R1--R8
，
R27.R28.R37.R38
207 3 002-1002021010R Resistor RES 1K OHM 1/10W 1% 0603 3 PCS R11.R16.R22
