Connection diagram - Bluetooth and AUX inputs
* Do not connect the Bluetooth module under any circumstance to the SIRIUS module
connector! Improper connection can cause permanent damage to Bluetooth/Interface module.
(front)
CarStream module
(back)
Bluetooth module
Vehicle Inter-
face Cable
Auxiliary device
(not included)
AUX cable
(optional)
CarStream module
Upgrade Port
USB to PC
or MAC computer
