Connection diagram
Do not connect an iPod dock cable under any circumstance to the SIRIUS module connector! Improper
connection can cause permanent damage to iPod/SIRIUS module.
MENU
CD changer cable
(3-pin and 6-pin BMW cables)
Sirius SC-C1 SAT tuner
AUX audio device
Microphone
MediaBridge module
MediaBridge vehicle connector
AUX connector
USB thumb drives
iPod
Sirius SC-C1 factory cable
USB cable or iPod docking cable
