Audison SR Series - 5 CH: FRONT + REAR + SUB

User’s Manual
62
SUB
Rem. Vol.
Control
SR 5.600
L
L L L
L
R
L
R
R
R R R
SPEAKER IN
REAR
SPEAKER IN
SUB
SPEAKER IN
FRONT
REAR
INPUT
FRONT
INPUT
SUB
INPUT
SUBWOOFER
min2Ω(L+R)
OUTPUTS
SOURCE
LR
X1
5CH: FRONT + REAR + SUB
SPEAKERS CABLE
16 mm / 0.62 in.
USE PRE-IN
OR SPEAKER IN:
NOT BOTH
*
**
HI
5 CH
REAR
LEVELS HI-PASS
SUB
LO-PASS LEVEL
FRONT
LEVELS HI-PASS
FRONT REAR
SUB INPUT
ON
If using SUB INPUT
select:
**
NOTE
OFF
If using FRONT INPUT only,
select:
REAR INPUT
*
NOTE
If using FRONT INPUT only,
select:
OFF
ON
If using REAR INPUT
select:
******
Adjustment
CONTROLS
Not
AVAILABLE
::
Set-up
CONTROLS
:
PASSIVE FILTERS
