Audison SR Series User Manual

User’s Manual
16
English / English
Before installing the components, please carefully read all of the instructions contained in this manual. It is advisable to carefully
follow the highlighted instructions. Failure to respect these instructions may cause unintentional harm or damage to the
components.
SAFETY CONSIDERATIONS
1. Makesureyourcarhas12VDCvoltagenegativegroundelectricsystem.
2. Checkyouralternatorandbatteryconditiontoensuretheycanhandletheincreasedconsumption.
3. Donotcarryoutanyinstallationinsidetheenginecompartmentorexposedtowater,excessivehumidity,dustordirt.
4. Neverruncablesoutsidethevehicleorinstalltheamplifiernexttoelectronicgearcases.
5. Installtheamplifierinthevehiclepartswheretemperatureisbetween0°C(32°F)and55°C(131°F).Lettheamplifierouterprofilebeatleast5cm(2”)far
 frompossiblewalls.Theremustbegoodaircirculationwheretheamplifierisinstalled.Ifyoucovertheheatsink,theamplifiergoesinprotection.
6. Theamplifiercanreachtemperaturesofaround80°C(176°F).Makesureitisnotdangerouslyhotbeforetouchingit.
7. Periodicallycleantheamplifierwithoutusingaggressivesolventsthatmightdamageit.Don’tusecompressedair,sinceitwouldpushsolidparts
 intheamplifiers.Dampenapieceofclothwithwaterandsoap,wringitandcleantheamplifier.Thenuseapieceofclothdampenedwithwateronly;
 eventuallycleantheamplifierwithadrypieceofcloth.
8. Makesurethelocationyouchoseforthecomponentsdoesnotaffectthecorrectfunctioningofthevehiclemechanicalandelectricaldevices.
9. Makesurepowercableisnotshortcircuitedduringinstallationandconnectionwiththebattery.
10. Useextremecautionwhencuttingordrillingthecarplate,checkingtherearenoelectricalwiringorstructuralelementunderneath.
11.Whenpositioningthepowersupplycable,avoidtorunthewireoverorthroughsharpedgesorclosetomovingmechanicaldevices.Userubber
 grommetstoprotectthewireifitrunsinaholeoftheplateorpropermaterialsifitisclosetoheat-generatingparts.
12.Makesureallthecablesareproperlysecuredallalongtheirlength.Also,makesuretheirouterprotectivejacketisflameresistantandself
 extinguishing.Useaclampingscrewtosecurepositiveandnegativecablesjustclosetotheamplifierrespectivepowersupplyterminalblocks.
13. Choosethecablegaugeaccordingtotheamplifierpowerandtothesuggestionsyoucanfindhere.Usehighqualitycables,connectorsand
 accessories,asyoucanfindintheConnectioncatalogue.
14. Pre-plantheconfigurationofyournewamplifierandthebestwiringroutestoeaseinstallation.
15.Inordertoavoidincidentaldamage,keeptheproductintheoriginalpackaginguntilyouarereadyforthefinalinstallation.
16.Alwayswearprotectiveeyewearwhenusingtools,assplintsorproductresiduemaybecomeairborne.
TYPICAL INSTALLATION SEQUENCE
If you have any questions please refer to the User’s Manual you can find available on www.audison.com or contact your AUDISON dealer or
AUDISON authorized service for assistance.
1. Beforeinstallingtheamplifierturnoffthesourceandallotherelectronicdevicesintheaudiosystemtopreventanydamages.
2. UsingacablewithadequateAWG(seechart:PowerSupplyCable),runthepowerwirefromthebatterylocationtotheamplifiermountinglocation.
3. Connectthepowersupplywiththecorrectpolarity.connect(+)terminaltothecablecomingfromthebatteryand(-)terminaltothecarchassis.
4. Putaninsulatedfuseholder40cmmaxfarfromthebatterypositiveterminal;connectoneendofthepowercabletoitaftertheotherendtothe
 amplifier.Donotmountthefuse.
5. Togroundthedevice(-)intherightway,useascrewinthevehiclechassis;scrapeallpaintorgreasefromthemetalifnecessary,checkingwith
 atesterthatthereiscontinuitybetweenthebatterynegativeterminal(-)andthefixingpoint.Ifpossible,connectallcomponentstothesame
 groundpoint;thissolutionrejectsmostnoisewhichcanbegeneratedduringtheaudioreproduction.
6. Routeallsignalcablesclosetogetherandawayfrompowercables.
7. ConnecttheRCAinputcables,theappliedsignalmustbebetween0.2VRMSand5VRMS.(SR 6.600: 0.32 VRMS - 8 VRMS)
8. Connectthehighlevelinputsusingtheproperplug.Appliedsignalmustbebetween0.8VRMSand20VRMS.(SR 6.600: 1.6 VRMS - 40 VRMS)
 Don’tuseitifyouarealreadyusingPreInpreamplifiedconnection.
9. Connectthespeakeroutputusing10AWGmaxspeakercable.
10.Don’tconnect(-)Land(-)Rspeakeroutputstogether.Ifyouuseanexternalstereocrossover,makesurethatitsnegativepolesarenotconnectedtogether.
11.Theamplifierturnsonbyconnectingtheremoteturnonterminal(REMOTEIN)tothesourcespecificoutput.Theamplifierturnsonautomatically,
 withoutremotesignal,alsoifusinghighlevelinputs(SpeakerIN)bysettingthe“AUTOTURNON”switchtopositionON.
12. TheLEDonthetoppanellightsupblueindicatingthattheproductison.TheLEDlightsuprediftheoutputsgoonoverload,ifthethermalprotection
 istriggered,ifthespeakercablesshortcircuitwiththevehiclechassisandiftheamplifierismalfunctioning.
13.Thefuse/sis/arelocatednearthepowersupplyandspeakerterminals.Toreplace,removethefuse/sfromthehousing.Alwaysreplacethefuse
 ofthesamerating.
14.Secureallauxiliarydevicesyoubuilttoinstallthecomponentstothevehiclestructure;thisinsuresstabilityandsafetywhiledriving.Theamplifier
 detachmentwhiledrivingcanseriouslydamagethepeopleinthevehicleandothercars.
15.Wheninstallationisover,checkthesystem’swiringandmakesureallconnectionsweredoneintherightway.
16.Putthefuseintothefuseholder.Thefusevaluewillhavetobe30%higherthantheamplifierbuilt-inone.Incasethecablesuppliesseveral
 amplifiers,thefusevaluewillhavetobe30%higherthanthesumofthevaluesofallotherfusesintheamplifiers.
17.Listeninglevelcalibrationismadebyadjustingthesourcevolumeupto3/4ofitsmaximumlevel;then,adjusttheamplifierlevelsuntilyouheardistortion.
18. WarrantyCertificate:pleasecheckouttheAUDISONwebsiteforfurtherinformation.
SAFE SOUND
USE COMMON SENSE AND PRACTICE SAFE SOUND. PLEASE REMEMBER THAT LONG EXPOSURE TO EXCESSIVELY HIGH SOUND PRESSURE
LEVELS MAY DAMAGE YOUR HEARING. SAFETY MUST BE AT THE FOREFRONT WHILE DRIVING
Information on electrical and electronic equipment waste (for those European countries which organize the separate collection of waste)
ProductswhicharemarkedwithawheeledbinwithanXthroughitcannotbedisposedoftogetherwithordinarydomesticwaste.Theseelectricalandelectronicproducts
mustberecycledinproperfacilities,capableofmanagingthedisposaloftheseproductsandcomponents.Inordertoknowwhereandhowtodelivertheseproductstothe
nearestrecycling/disposalsitepleasecontactyourlocalmunicipaloffice.Recyclinganddisposingofwasteinaproperwaycontributestotheprotectionoftheenvironment
andtopreventharmfuleffectsonhealth.
