21005 V3
8 Capabilities
• Versatile 2 x 60W configuration with additional option to parallel both
amplifiers for a single 120W output.
• Liquid Crystal bar graph text in multiple languages.
• Three microphone/line inputs plus a dedicated music input.
• Three output zones with zone selection.
• Separate volume controls on all microphone/line inputs.
• Independent volume and tone controls on music.
• Optional pre-announce chime.
• Priority system for microphone/line inputs.
• Proven MOSFET design with in-built open and short circuit protection..
• Overload protection, with self re-setting thermal shutdown characteristic.
• High integrity connectors throughout.
• Optional pre-announce chime.
• Attractive microphone unit in matching style.
• Slim line case for use in a host of retail, pub and club, hotel, restaurant,
service station and medical centre applications.
• Standalone or 19" rack mounted versions available.
• LED on microphone console for busy or chime indication.
9 Specification
Rated power
60W + 60W rms.
Output voltage
100V rms.
Alternative
outputs
4 Ohms, 8 Ohms, and 50V
Frequency
response. (-3dB)
100Hz to 20kHz.
Tone controls
(Music and Mics
have separate
controls).
Bass
Treble
+12dB at 100Hz
+12dB at
10kHz.
Distortion (THD).
Better than 1% at rated output
typically less than 0.1% at 1kHz.
Signal/Noise.
Better than -80dB 22Hz-22kHz
Sensitivity. (10dB
gain in hand on
volume controls)
Mic input 0.7mV (-60dBu)
Line input 70mV (-20dBu)
Music input 70mV (-20dBu)
Case Dimensions
430mm x 335mm x 80mm
Weight
11.5 Kg
Power
requirements
240V AC mains 1 Amp max.
OR
24V DC 10 Amps max
Quiescent current requirement: 300mA at 24
V dc (typical 240mA) (Battery units with built
in chargers are available from the Audix
