auer HTi70 6 - A1 - Technical Specifications; A1.1 - General Characteristics; A1.2 - Performances

- MANUAL HTi
70
6 & 8 KW HEAT PUMPS -
18
APPENDIX
A1 - Technical specifi cations
A1.1 - General characteristics A1.2 - Performances
155000
HTi
70
6kW
155010
HTi
70
8kW
Maximum temperature 70 °C 70 °C
R290 refrigerant fl uid 0.420 kg 0.600 kg
Range of exterior air temperature -15 to +40 °C -15 to +40 °C
Electrical supply 230 V single 230 V single
Maximum current needed 15 A 15 A
Progressive starter no no
Head protection 16 A single 16 A single
Power cable cross-section 3 x 2,5 mm
2
3 x 2,5 mm
2
Construction steel steel
W 1035 mm 1035 mm
Dimensions H 820 mm 1070 mm
P 480 mm 480 mm
Weight when empty 92 kg 98 kg
Nominal water fl ow rate 1050 l/h 1350 l/h
Hydraulic connection 26 / 34 male 26 / 34 male
Maximum hydraulic pressure 2.5 bars 2.5 bars
Ø condensates drainage 18 / 22 mm 18 / 22 mm
Max air fl ow rate 3500 m
3
/h 3500 m
3
/h
Sound levels at 1m 52,1 dB(A) 55,6 dB(A)
155000
HTi
70
6kW
Exterior
temperature
Water regime
30/35 40/45 47/55 55/65
MAX heat ouput
12 °C
6,00 6,00 6,00 6,00
Nominal heat ouput*
2,90 2,95 2,92 2,94
COP*
5,67 4,03 3,08 2,40
MAX heat ouput
7°C
6,00 6,00 6,00 6,00
Nominal heat ouput*
4,17 4,22 4,27 4,19
COP*
5,05 3,76 3,04 2,38
MAX heat ouput
2 °C
6,00 6,00 6,00 6,00
Nominal heat ouput*
4,57 4,51 4,56 4,58
COP*
3,97 3,17 2,63 2,19
MAX heat ouput
-7 °C
6,00 6,00 5,70 5,50
Nominal heat ouput*
4,93 5,16 5,11 5,33
COP*
2,98 2,58 2,19 1,92
MAX heat ouput
-15°C
5,50 4,64 4,14 3,92
Nominal heat ouput*
4,58 3,87 3,60 3,56
COP*
2,45 2,22 1,95 1,76
* According to EN 14511 standard
155010
HTi
70
8kW
Exterior
temperature
Water regime
30/35 40/45 47/55 55/65
MAX heat ouput
12 °C
8,00 8,00 8,00 8,00
Nominal heat ouput*
3,95 4,04 4,07 4,03
COP*
6,54 4,62 3,89 3,22
MAX heat ouput
7°C
8,00 8,00 8,00 8,00
Nominal heat ouput*
6,06 6,04 6,01 6,07
COP*
5,35 4,21 3,42 2,91
MAX heat ouput
2 °C
8,00 8,00 8,00 8,00
Nominal heat ouput*
6,22 6,21 6,45 6,44
COP*
3,75 3,24 2,88 2,44
MAX heat ouput
-7 °C
8,00 7,76 7,45 6,85
Nominal heat ouput*
6,62 6,59 6,58 6,41
COP*
3,04 2,62 2,22 2,05
MAX heat ouput
-15°C
6,70 6,00 5,50 5,00
Nominal heat ouput*
5,38 4,88 4,64 4,54
COP*
2,53 2,34 2,05 1,82
* According to EN 14511 standard
