2. Loosen 3 screws of the board, turn board to the new position and fasten the
screws.
3. Check whether O-ring is in good condition, correctly insert O-ring.
4. Turn local controls into new position and re-place.
Cable damage due to twisting or pinching!
Risk of functional failures.
→
Turn local controls by a maximum of 180°.
→
Carefully assemble local controls to avoid pinching the cables.
5. Fasten screws evenly crosswise.
15
SQ 05.2 – SQ 14.2/SQR 05.2 – SQR 14.2
AMB 01.1 Assembly
