Actuator controls AUMATIC AC 01.1 / ACExC 01.1
Profibus DP Operation instructions
16
35
35
38
36
36
37
B
B
A
A
B
A
Figure D-5: Bus connection for channel 2
(component redundancy only)
from the previous
Profibus DP device
channel 2
to the next
Profibus DP device
channel 2
Another bus station follows the actuator
Actuator is the final bus station
31
31
34
32
32
33
B
B
A
A
B
A
Figure D-4: Bus connection for channel 1
(Standard)
Another bus station follows the actuator
Actuator is the final bus station
from the previous
Profibus DP device
channel 1
To the next
Profibus DP device
channel 1
Technical data Motor power connections
1)
Protective earth Control pins
No. of contacts max. 3 1 (leading contact) 38 pins / sockets
Marking U1, V1, W1 according to VDE 1 to 24, 31 to 50
Voltage max. 550 V 250 V
Current max. 25 A 10 A
Type of customer connection Screws Screws Screws
Cross section max. 6 mm
2
6 mm
2
1.5 mm
2
Material: Pin / socket carrier Araldite / Polyamide Araldite / Polyamide Araldite / Polyamide
Contacts Brass (Ms) Brass (Ms) Brass (Ms) tin-plated
1) Suitable for copper wires. For aluminium wires contact AUMA.
Table 5: Technical data Ex-plug/ socket connector with terminal board for explosion-proof actuators
