Features and functions
Coupling without boreStandard:Splined coupling for connection to
the valve shaft
Machined coupling with bore and keyway, square bore or bore with two-flats according to
EN ISO 5211
Options:
Dimensions according to EN ISO 5211 without spigotValve attachment
Mit Fuß und Hebel (Option)
Aus Sphäroguss mit zwei oder drei Bohrungen zum Befestigen eines Gestänges. Der Hebel kann über
eine Kerbverzahnung, unter Berücksichtigung der äußeren Gegebenheiten, in beliebiger Lage auf die
Antriebswelle montiert werden.
Schwenkhebel
Zwei Kugelgelenke, passend zu Hebel, einschließlich den Kontermuttern und zwei Anschweißenden
passend zu Rohr nach Maßblatt.
Kugelgelenke (Option)
Fuß und vier Bohrungen für BefestigungsschraubenBefestigung
Electronic control unit
Magnetic limit and torque transmitter (MWG)Non-Intrusive setting
Via actuator controlsPosition feedback signal
Via actuator controlsTorque feedback signal
Blinking signal via actuator controlsRunning indication
Resistance type heater with 5 W, 24 V ACHeater in switch compartment
Service conditions
Indoor and outdoor use permissibleUse
Any positionMounting position
≤ 2,000 m above sea level
> 2,000 m above sea level on request
Installation altitude
Refer to actuator name plateAmbient temperature
Up to 100 % relative humidity across the entire permissible temperature rangeHumidity
IP68
Refer to name plates at motor and actuator for exact version
Standard:Enclosure protection according to
EN 60529
DS terminal compartment additionally sealed against interior of actuator (double sealed)Option:
According to AUMA definition, enclosure protection IP68 meets the following requirements:
●
Depth of water: maximum 8 m head of water
●
Duration of continuous immersion in water: Max. 96 hours
●
Up to 10 operations during immersion
●
Modulating duty is not possible during immersion
Pollution degree 4 (when closed), pollution degree 2 (internal)Pollution degree according to
IEC 60664-1
KS: Suitable for use in areas with high salinity, almost permanent condensation, and high
pollution.
Standard:Corrosion protection
KX: Suitable for use in areas with extremely high salinity, permanent condensation, and
high pollution.
Option:
Double layer powder coating
Two-component iron-mica combination
Coating
AUMA silver-grey (similar to RAL 7037)Standard:Colour
Available colours on requestOption:
AUMA part-turn actuators meet or exceed the lifetime requirements of EN 15714-2. Detailed information
can be provided on request.
Lifetime
< 72 dB (A)Sound pressure level
74
SQV 05.2 – SQV 14.2 / SQRV 05.2 – SQRV 14.2 Control unit: electronic (MWG)
Technical data ACV 01.2 Non-Intrusive Profibus DP
