Configuration of digital inputs
Required user level: Specialist (4) or higher.
Device configuration M0053
I/O interface M0139
Digital inputs M0116
Example
Use input DIN4 for signal Bypass Sync In:
Use input DIN6 for signal EMERGENCY:
Setting values:
●
Signal DIN 5 M0122 = By-pass Sync In
(wiring diagram designation: BYPASS SYNC IN)
●
Signal DIN 6 M0121 = EMERGENCY
(wiring diagram designation: NOT/EMERGENCY)
Information
The logic for the digital inputs may be inverted. Depending on the parameter setting
(e.g. Coding DIN 6 M0128), the input is either High active or Low active. Default
setting is High active.
Configuration of digital output
Required user level: Specialist (4) or higher.
Device configuration M0053
I/O interface M0139
Digital outputs M0110
Example
Use output DOUT6 for signal Bypass Sync Out:
Parameters: Signal DOUT 6 M0111
Setting value: Bypass Sync Out (wiring diagram designation: BYPASS SYNC
OUT)
8.14.1. By-pass function: activate
Required user level: Specialist (4) or higher.
Device configuration M0053
Application functions M0178
Activation M0212
By-pass function M0941
Default value: Function not active
Setting values:
Function not active
Bypass function deactivated.
Function active
Bypass function activated.
8.14.2. By-pass application: configure
The actuators for the two MOVs (valves) have to be configured according to their
application (main or by-pass valve).
Customer settings M0041
By-pass function M0942
By-pass application M0943
Default value: Main valve
Setting values:
Main valve
Actuator for main valve.
By-pass valve
Actuator for by-pass valve.
80
Actuator controls
Application functions ACV 01.2/ACVExC 01.2 Profibus DP
