11
2-WAY (Regular)
Position - choice of listening position.
All / Front Left / Front Right / Front All.
X’over reset
Reset crossover settings.
IMPORTANT! The delay setting starts from the farthest speaker from
listening position (usually a subwoofer).
The farthest speaker does not need additional delay.
The rest of the speakers must be corrected according to the difference between the
distance from the farthest speaker and the distance from the calculated speaker to
the listening position.
Make the necessary calculations for all speakers, then make the settings in the app
or in the receiver's menu.
Per-channel setting of signal time delays. The settings of this menu item will be
different for configurations 2-WAY / 3-WAY!
DTA SETTING - delay setting
3-WAY (Network)
Tweeter - HPF setting for tweeters.
HP FRQ - Cutoff frequency: 500 / 630 / 700 / 800 / 1 / 1.6 / 2.5 / 3.15 / 4 / 5 / 6.3 / 8 /
10 / 12.5 kHz.
SLOPE (High-High Frequency Slope) - the steepness of the decline: 6 / 12 / 18 / 24 dB
per octave.
PHASE (HF PHASE) - electrical phase switching: 0° / 180°
GAIN (HF LEVEL) - the volume level of the tweeters, from -8 dB to 0 dB.
Mid range - adjusting the high-pass filter (HPF) and low-pass filter (LPF) of the
midrange speakers
HPF FRQ (MF-HPF) - HPF cutoff frequency (HPF): THROUGH (off) / 30 / 40 / 50 / 60 / 70 / 80 / 90 /
100 / 120 / 150 / 180 / 220 / 250 / 315 / 400 / 500 / 630 / 700 / 800 Hz.
HPF SLOPE (MF-HFT DECAY) - the steepness of the decline: 6 / 12 / 18 / 24 dB per octave.
LPF FRQ (MF-LPF) - cutoff frequency: 500 / 630 / 700 / 800 / 1 / 1.6 / 2.5 / 3.15 / 4 / 5 / 6.3 / 8 / 10 /
12.5 kHz / THROUGH (off).
PHASE (MF PHASE) - electrical phase switching: 0° / 180°
LPF SLOPE (MF-LPF SLOW) - the slope of the LPF slope (LPF): 6 / 12 / 18 / 24 dB / oct.
GAIN (MIDDLE LEVEL) - the volume level of the midrange speakers, from -8 dB to 0 dB.
Woofer - low-pass filter (LPF) and subwoofer phase adjustment
LPF FRQ (SUB LPF) - cutoff frequency: 30 / 40 / 50 / 60 / 70 / 80 / 90 / 100 /
120 / 150 / 180 / 220 / 250 / 315 / 400 / 500 / 630 / 700 / 800 Hz THROUGH (off).
SLOPE (SAB-LPF SLOW) - the steepness of the decline: 6 / 12 / 18 / 24 dB per octave.
PHASE (SUB PHASE) - electrical phase switching: 0° / 180°
GAIN (SUB LEVEL) - subwoofer volume level, from -8 dB to 0 dB.
X-OVER
