4
Open the package and make sure that there are inside:
1. USB resaver - 1 pc.
2. The remote control - 1 pc.
3. Keys for removing the receiver - 2 pcs.
4. The main connector is 1 pc.
5. RCA connector - 1 pc.
6. Instruction
Package and installation
1. Install the mounting casing in the hole of the 1din standard,
provided by the manufacturer. If the regular place has a 2DIN size,
use transitional frames and adapters of the brand.
2. Light out the metal tongues on the mounting casing to fix it in place.
3. Check electrical connections, connector or individual wires
(depends on the configuration of a particular car model).
Connect the main connector to the device. Check
The system performance before fixing in the mounting casing.
4. Insert the device into the mounting casing and push it inward to
fixation by click.
In some brands of cars (for example, Toyota, Honda, ...), the device is mounted
by screws to standard brackets.
In this case, the mounting casing is not used.
1
2
3
Connect the required wires
and connectors
4
Installation of the device
