CH 200 / CH 250
(fig. 2)
(fig. 3)
(fig. 4)

Towing the machine
If the machine must be towed for short distances, only do so with a solid tow-bar to prevent any
lateral sway. Attach the tow bar to the bolt at the rear of the counter weight (fig.2). Drive slowly
and carefully at a speed not exceeding 6 mph. Comply with all state laws governing the opera-
tion / towing of an off-highway machine on public roads and highways.
Before towing the machine:
Tight the screws of the safety relief valve on the hydrostatic pump to allow the relief of the fluid.
(See arrows on fig.3). To have the machine again on working position, loose these screws and
tight the nuts again.
Remove the negative brake group on the reductor gear. To carry out it, loose the nuts and take
out them from the studs. (See arrows on fig.4).
After assembling again the brake group, check that the 0,042 USgal of oil remain inside, add oil
if necessary.
