Electric circuit CH250 5
46
CH 200 / CH 250
Item Description Sh. Item Description Sh.
A28 Pre-heat relay 1 M15 Rear wiper motor 4
A39 Horn 2 M20 Electric fuel pump 3
E12 Left hand headlight 4 M25 Starter motor 1
E13 Right hand headlight 4 M32 Windscreen washer motor 3
F1 Low beam fuse (10A) 4 P52 Instrument panel 1
F2 High Beam fuse (10A) 4 R21 Pre-heater plugs 1
F3 Side lights / brake lights / reverse relay fuse (7'5A) 4 S16 Air filter blockage indicator 1
F4 Front windscreen wiper fuse (15A) 3 S18 Hydraulic oil level sensor 1
Ignition feed stop solenoid / fuel pump / pre-heating /
alternator fuse (7'5A)
1 S23 Coolant temperature warning switch 1
F6 Ignition feed warning lights / horn fuse (10A) 4 S24 Engine oil pressure switch 3
F7 Seat switch / timer relay fuse (7'5A) 2 S33 Seat switch 3
3rd.and 4rth.service solenoids (sideshift or attachments)
fuse (7'5A)
2 S40 Brake lights switch 3
F9 Dash panel lights / heater motor fuse (10A) 1 S51 Ignition barrel 1
F10 Flashing / rotating beacon and working lights fuse (15A) 4 S53 Hazard light switch 4
F11 Permanent live warning lights switch (5A) 4 S54 Indicator switch 4
FG1 Permanent live main fuse (50A) 1 S55 Headlight / sidelight switch 4
FG2 Starter motor relay main fuse (50A) 1 S56 Rotating / Flashing beacon switch 4
FG3 Pre-heat relay main fuse (30A) 1 S57 Worklight switch 4
FG4 Battery main fuse (200A) 1 S58 Heater motor switch 3
G19 Battery 1 S59 4x4 switch (not used) 2
G26 Alternator 1 S60 Front windscreen wiper switch 3
H1 Right hand reverse light 4 S61 Handbrake switch 2
H2 Brake and tail lights right hand side 4 S99 Joystick spool valve lock link connector 3
H3 Rear right hand indicator 4 S100 Forward and Reverse switch (joystick) 2
H5 Rear left hand indicator 4 S101 Horn switch (joystick) 2
H6 Brake and tail lights left hand side 4 S102 2 Speed selector switch (joystick) 2
H7 Left hand reverse light 4 S103 3rd. service switch (side shift) (joystick) 2
H9 Number plate light 4 S104 4rd. service switch (attachments) (joystick) 2
H14 Work lights 4 S31a Fuel tank gauge 3
H17 Reverse alarm 3 S31b Low level fuel warning light 3
H45 Rotating / Flashing beacon 4 Y22 Engine stop solenoid 1
H71 Dash panel buzzer (warning lights) 1 Y29 Forward solenoid 2
K62 4x4 timer relay (not used) 2 Y30 Reverse solenoid 2
K63 Seat switch timer relay 2 Y34 Parking brake solenoid 3
K64 Flasher relay 4 Y35 2 Speed solenoid (not used) 2
K65 Neutral start relay 1 Y36 Joystick spool valve lock units 3
K66 4x4 low speed relay (not used) 2 Y37 3rd. service solenoid (side shift) 2
K67 Reverse alarm relay (night silence) 2 Y38 4rd. service solenoid (attachments) 2
K68 Starter motor relay 1 Y39 Brake assistance solenoid 3
K69 Stop Solenoid relay 1
Remark: In the bicolor cables, the longitudinal or traverse shape of the marks on the protective coating are to indicate the color. For example:
G - V: Yellow / Green with traverse marks
G / V : Yellow / Green with longitudinal marks
