AUTEC - Air series
Technical data 3
LIRMGE00-01
2 Technical data
Power supply ........................................................................................... 12-24V (1.2A)
Power supply protection fuse ....................................................... 3.15A T 250V (5x20mm)
Digital inputs voltage .......................................................................................... 12-24V
Antenna ............................................................................................. internal or dedicated
STOP contacts rated current ........................................................................... 6A (30V )
STOP contacts protection fuses ....................................................... 6A T 250V (5x20mm)
SAFETY contacts rated current ..................................................................... 10A (30V )
SAFETY contacts protection fuses ................................................. 10A T 250V (5x20mm)
Rated current of outputs of solid state commands ........................................... 4A (30V )
Rated current of relay commands' outputs
a
.................................................. 10A (30V )
b
Housing material .......................................................................................... PA 6 (20%fg)
Protection degree ....................................................................................... IP65 (NEMA 4)
Weight ........................................................................................................... 2.2kg (4.9Lb)
a. Command contacts' rated current for any optional card is provided in the technical data sheet.
b. The rated current may be up to 10A only if both terminals are used for each contact. If the radio
remote control has been wired by Autec, please refer to values provided in the technical data
sheet.
