Diagnostics Toolbar
The Diagnostics Toolbar contains a number of buttons such as print and save.
The table below provides a brief description of the operations of the Diagnostics
Toolbar buttons:
Table 4-2 Diagnostics Toolbar Buttons
Returns to the MaxiCOM Job Menu.
Exits the service session of the currently identified
test vehicle and returns to the vehicle menu screen.
Opens the setting screen. See Settings Operations
on page 86.
Prints a copy of the displayed data. See Printing
Operation for additional information on page 14.
Displays operational instructions or tips.
Tap this button to open a submenu, on which there
are three options available to save the displayed
data.
Tap Save This Page to take a screenshot
Tap Save All Data to save a PDF file (mostly
used to save data that cover more than 1 page)
Tap Start Saving to record a video clip (only
available for recording Live Data or special
graph data)
All saved data is stored in the Data Manager
application for later reviews. See Data Manager
Operations on page 72.
Records the communication data and ECU
information of the test vehicle. The saved data can
be reported and sent to the technical center via the
internet.
You can go to the Support application to follow up
the processing progress, see Data Logging on page
104 for detailed information.
