Chapter 2 General Introduction
The MaxiCOM
®
MK906 is an advanced diagnostic device developed for customers
looking for a tool with ultra-convenient and modern design while delivering ultimate
performance. Featuring the powerful Samsung Exynos 5260 6-core processor (1.3 GHz
quad-core ARM Cortex-A7 + 1.7 GHz dual-core ARM Cortex-A15), and an 8.0 inch LED
capacitive touch screen, based on the Android multitasking operating system, and
combined with the best possible coverage of OE-level diagnostics, the MaxiCOM MK906
is an ideal solution to manage your repair jobs smartly and conveniently with greater
integration.
This manual describes the construction and operation of the device and how it works to
deliver diagnostic solutions.
MaxiCOM MK906 Display Tablet
2.1.1 Functional Description
Figure 2-1 MaxiCOM MK906 Tablet Front View
1. 8.0” LED Capacitive Touch Screen
2. Power LED – indicates battery level & charging or system status.
3. Vehicle Communication LED – flashes green when the Display Tablet is
communicating/linking with the vehicle’s system.
4. Ambient Light Sensor – detects ambient brightness.
5. Microphone
