43
Figure 4-14 Sample OBD II Diagnostic Menu
NOTE: Tapping the
○
i button displayed beside the function name opens
a bubble with additional function information.
4. Select a function option to continue.
DTC & FFD
I/M Readiness
Live Data
O2 Sensor Monitor
On-Board Monitor
Component Test
Vehicle Information
Vehicle Status
NOTE: Not all functions are supported by all vehicles.
4.7.2 Function Descriptions
This section describes the various functions of each diagnostic option:
DTC & FFD
When this function is selected, the screen displays a list of Stored and Pending
Codes. A snowflake button will display on the right side of the DTC item when
the Freeze Frame data is available for viewing. Tap Clear DTC to erase codes.
