141
4. Follow the step-by-step on-screen instruction to complete the
service. Take Auto oil reset as an example.
5. Tap Auto oil reset on the Oil Reset function list to start the operation.
The screen will notify you to turn the ignition switch to position 2, the
engine must be off.
6. The screen will display Reset SRL data Routine completed once the
operation is successfully done. Tap OK to exit. The operation
procedure varies by function, please follow the onscreen
instructions to complete.
Figure 7-3 Sample Oil Reset Service Screen 2
Figure 7-2 Sample Oil Reset Service Screen 1
