9
LED
Color
Description
Connection
Green
Illuminates solid green when properly
connected with the display tablet via the USB
cable.
Blue
Illuminates solid blue when connected with the
display tablet via wireless (BT) connection.
Power
Green
Illuminates solid green when powered on.
Red
Flashes red when system failure occurs.
Amber
The power LED illuminates amber
automatically every time when the device is
power up, which is a normal self-test
procedure, and it will turn green automatically
later when the device starts working normally.
Technical Specifications
Table 2-3 Specifications
Name
Value
Communications
Wireless BT V2.1 + EDR,
USB 2.0
Wireless Frequency
Wireless BT V2.1+EDR, 2.4GHz
Input Voltage Range
12VDC to 24VDC
Supply Current
170mA @ 12VDC
100mA @ 24VDC
Operating Temperature
-10℃ to +50℃ (ambient)
Storage Temperature
-20℃ to +60℃ (ambient)
Dimensions (L*W*H)
149 mm * 86mm * 35 mm
