ENTER BUTTON -- Confirms a selection (or action) from
a menu. Starts recording live data under manual trigger mode.
②
ESC BUTTON -- Cancels a selection (or action) from a
menu or returns to the menu. It is also used to setup system, exit
DTC Lookup screen, or stop data recording when pressed.
③
LEFT SCROLL BUTTON -- When look up DTC
definitions, moves to previous character and views additional
information on previous screens if DTC definition covers more
than one screen; deselect all marked PID data when viewing or
recording customized live data list; views previous frames of
recorded data when playing back live data. It is also used to
update DTC library when pressed.
④
RIGHT SCROLL BUTTON -- When look up DTC
definitions, moves to next character and view additional
information on next screens if DTC definition covers more than
one screen; selects/deselects PID data when viewing or
recording customized live data list, and views next frames of
data when playing back live data.
⑤
UP SCROLL BUTTON -- Moves up through menu and
submenu items in menu mode. When more than one screen of
data is retrieved, moves up through the current screen to the
previous screens for additional data.
⑥
DOWN SCROLL BUTTON -- Moves down through menu
and submenu items in menu mode. When more than one screen
of data is retrieved, moves down through the current screen to
next screens for additional data. It is also used as the language
setup hotkey when pressed.
⑦
HELP BUTTON -- Provides help information when
pressed.
⑧
POWER SWITCH -- Turns on/off the scan tool when
powered by cell battery; resets the scanner when powered by
vehicle battery.
⑨
⑩ OBD II CONNECTOR -- Connects the scan tool to the
vehicle’s Data Link Connector (DLC).
9
