Tool Information
Serial No. : MS083462
Burn Date: 11/12/07
S/W Ver : V1.00
H/W Ver : V1.01
LIB Ver : V1.00
3.10 Battery Replacement
The scan tool requires a 9V cell battery to operate when
disconnected from vehicle power. When the icon
appears on the
screen, replace the battery.
1) Locate the battery cover on the back of the scan tool.
2) Remove the battery cover screw and slide the battery cover off.
3) Remove discharged batteries and install a new 9V cell battery.
4) Reinstall battery cover by sliding battery cover on and installing
screw.
3.11 Vehicle Coverage
The Maxiscan
TM
MS509 OBDII/EOBD Scanner is specially designed
to work with all OBD II compliant vehicles, including those equipped
with next-generation protocol -- Control Area Network (CAN). It is
required by EPA that all 1996 and newer vehicles (cars and light
trucks) sold in the United States must be OBD II compliant and this
includes all Domestic, Asian and European vehicles.
A small number of 1994 and 1995 model year gasoline vehicles are
OBD II compliant. To verify if a 1994 or 1995 vehicle is OBD II
compliant, check the Vehicle Emissions Control Information (VECI)
Label which is located under the hood or by the radiator of most
vehicles. If the vehicle is OBD II compliant, the label will designate
“OBD II Certified”. Additionally, Government regulations mandate
that all OBD II compliant vehicles must have a “common”
sixteen-pin Data Link Connector (DLC).
21
