36
Recording Complete Data Set
2) To record complete set of live data, use UP/DOWN scroll button
to select Complete Data Set from Record Data menu and press
ENTER button.
3) Use UP/DOWN scroll button to select a trigger mode and press
ENTER button.
z If data from previously tested vehicle is not erased, data from
current test will be stored in a temporary cache.Following
screen shows when Manual Trigger is selected:
………………..Record Data……… ……..
1/3
……………….Live Data…………………….
2/3
View Data
►Record Data
Playback Data ?
►Complete Data Set
Custom Data Set
Unit of Measure ?
…….……Pick Trigger Mode……… ……
1/2
► Manual Trigger
DTC Trigger ?
