z If DTC Trigger is selected, following screen shows:
………… DTC Trigger…… … …
Waiting for DTC to
trigger recording…
Press [ESC] to exit
14) Wait for DTC to trigger recording or press ENTER to start
recording.
44
………… Recording… 5/60….
6
DTC_CNT 6
FUELSYS1 OL
FUELSYS2 N/A
LOAD_PCT(%) 0.0
ETC(℃) -40
15) The scan tool keep recording PID data until user presses ESC
button, the selected memory location is full, or it completes
recording. A message prompting to playback data shows on the
screen.
z If you wish to playback recorded data, press ENTER button;
if you do not wish to playback, press ECS button, or use
►SHRTFT1(%) 0.0
………………..Record Data………………
Record Done!
Playback data?
YES NO
