Functional Description
1. Lighting Push Button
2. Power LED
3. Vehicle/Connection LED
4. Vehicle Data Connector (16-Pin) – connects the MaxiVCI V200 to the
vehicle’s 16-pin DLC directly.
5. USB Port – provides the easiest connection between the device and the
display tablet via a USB cable.
Technical Specifications
Table 2- 4 Specifications
Item
Description
Communications
 EDR
 USB 2.0
Wireless Frequency
2.4 GHz
Input Voltage Range
6 V-36V DC
Supply Current
150 mA @ 12V DC
Operating Temp.
-10°C to 60°C (14°F to 140°F)
Storage Temp.
-40°C to 80°C （-40°F to 176°F)
Dimensions
(
L x W x H
)
89.89 mm (3.53”) x 46.78 mm (1.84”) x 21
mm (0.82”)
Weight
70.7g (0.156 lb.)
Built-in Battery
3.7V Lithium Battery
Light
White LED
Other Accessories
Table 2- 5 Accessories
