AUTO ARC Explorer Series - Variable Shade Control (No. 9 − 13)

OM-261 661 Page 7
3-5. Variable Shade Control (No. 9 − 13)
1 Variable Shade Control
(No. 9 − 13)
Use the control to adjust the lens
shade in the darkened state. Use
the table in Section 1-4 to select
proper shade control setting
based on your welding process.
Start at shade 12 or 13 and adjust
lighter to suit the welding applica-
tion and your personal preference.
