MOUNTING AND INSTALLATION
3203 SERIES
3-3.0
02/15/06
1. Check to make sure the following items are with your crane.
Common Parts
ITEM
QTY
PART NO. DESCRIPTION
1 1 320433000 TRAVELING BLOCK
2 6 083800000 CLIP NO 838
3 4 404226000 SCREW HX HD 3/4-16 UNF X 3"LG GRADE 8
4 4 404227000 NUT, HEX 3/4-16 UNF
5 4 022101000 WASHER SP LK. 3/4
6 4 022102000 WASHER FL 3/4
7 1 320950000 OWNER'S MANUAL 3203
8 1 600425000 CABLE POWER TWECO
9 1 320806000 CONDUCTOR ASSY 10 GA X 48"LG BLACK
Model Specific Parts
MODEL
QTY
PART NO. DESCRIPTION
PR 1 320922000 PENDANT ASSEMBLY PR
PRX 1 320921000 PENDANT ASSEMBLY PRX
PRXD 1 320920007 TRANSMITTER 3203 PRXD
PRD 1 320920008 TRANSMITTER 3203 PRD
PRD
PRXD
1 366500009 PENDANT CABLE
PRD
PRXD
1 366504000 CIGARETTE LIGHTER CHARGER
2. Vehicle should meet minimum GVW rating of 8,800 pounds. (does not include bodies or accessories)
3. Make sure mounting surface is properly reinforced to withstand 9,600 ft-lb capacity loading of crane and
that outriggers are used to provide total stability for the truck.
4. A 9” dia. hole should be cut out of mounting location (centered with mounting bolts) for access.
Reference general dimensions for bolt pattern.
5. Make sure the mounting bolts are 3/4”-16UNF, grade 8. Torque bolts to 335 ft-lbs (dry).
6. When crane is not in operation, a boom support should always be used. Traveling block should be
connected to hook loop.
7. See following page for installation.
8. See the following pages for additional electrical installation.
9. Load test the crane to ensure proper functioning and truck stability
10. Make certain the owner’s manual is delivered to the customer.
11. For additional help: call the service department at the Auto Crane Company. (918) 836-0463 (Tulsa,
Oklahoma)
