Auto Crane 3203 PR - Page 35

PEDESTAL ASSEMBLY
3203 SERIES
5-5.0.0
05/22/2003
ITEM NO. QTY. PART NO. DESCRIPTION
38 6 021100 WASHER SPLK 3/8
39 6 330371 SCW HX 3/8 UNC X 1 GR8
40 2 011603 SCREW HEX .5-13 X 1.75
41 3 007401 SCW 5/16-18 X 1/2 LG
42 1 320917000 PRESSURE SWITCH, N.C. 1,900 PSI
43 4 200876 FITTING 6 SAE/6 JIC STRAIGHT 6F5OX
44 2 490198 FITTING 10SAE(M)/6JIC ELBOW 90
45 1 320333 RETAINING RING, SNAP RING
46 1 320891000 BRUSH ASSEMBLY
47 1 320442 GUARD CABLE RETAINER
48 2 812026023 HOSE ASSY -4 HOSE -6 FEMALE JIC
49 4 812026016 HOSE ASSY -4 HOSE -6 FEMALE JIC
50 2 320927000 HOSE ASSY -4 HOSE -6JIC/-6JIC 90 X 20
51 1 320925000 BRACKET, BOOM LIMIT
52 1 646900 SWITCH, ANTI-TWO BLOCK
53 1 320926000 BRACKET, BOOM LIMIT STOP
54 1 642908 CORD CONNECTOR
55 1 002900 SCREW SET 0.25-20 X 0.25
ITEM 50 ONLY USED ON PRX MODELS
