BOOM ASSEMBLY
3203 SERIES
5-7.0.0
05/22/2003
ITEM NO. QTY. PART NO. DESCRIPTION
1 1 320831000 LOWER BOOM WELDMENT
2 1 320832000 MI D BOOM WELDMENT
3 1 320833000 UPPER BOOM WELDMENT
4 1 320871000 BAI L WELDMENT
5 1 320883000 SHEAVE ASSEMBLY
6 1 320835000 CYLI NDER, EXTENSI ON
7 2 320888000 RETAI NER EXTENSI ON CYLI NDER
8 1 360765000 WEAR PAD 2 .50 X 3 .25
9 3 360767000 PAD BOOM 1.5 O.D.
10 1 360792000 WEAR PAD 2 X 3.5 X 3/8
11 1 320391 RETAI NER MI D BOOM
12 12 007807 SCW HEX 5/16-18 3/4LG GR5
13 1 320554 SPRI NG RETURN
14 1 320328 PI N ASSY .625 X 4.5 W/LANYARD
15 1 007800 SCREW HEX 0.3125-18 X 2
16 1 016801 NUT HEX-LOCK 5/16 NC
17 6 020200 WASHER SPLI T LOCK 1/4
18 6 005406 SCW HX 1/4-28 X 1/2
19 1 320858000 BEARI NG, SPHERI CAL 1.00 I D
20 2 320868000 BEARI NG PI VOT
21 1 646900 SWI TCH, ANTI -TWO BLOCK
22 2 320884000 PULL HANDLE, MANUAL BOOM
23 1 018200 NUT .625-11 NYLON LOCK
24 1 366393 HEX HEAD 5/8-11 X 2.5 GR8
25 1 320889000 PI N, EXTENSI ON CYLI NDER
26 2 360122 RI NG RETAI NI NG 5100-98
27 1 320899000 CORD REEL ASSY
28 1 320907000 PULL PI N ASSEMBLY
29 2 320912000 DOU BLER, I NSIDE BOOM
30 1 642918 CORD CONNECTOR
31 1 320880000 PIN, LOWER/MID PR
I TEMS 6, 25 & 26 NOT USED ON PR M ODELS
IN ADDITION TO THE ABOVE, THE FOLLOWING IS NECESSARY ON PR
MO D ELS
