HOIST ACTUATOR
3203 SERIES
5-10.0.0
05/22/2003
PIPE PLUG320382266
SCREW, 1/4−20NC x 1" LG. ALL THREAD360453265
WASHER, FIBER300082164
WASHER, THRUST300081163
WASHER, THRUST300080362
SPRING360368161
RING, SNAP300079160
SEAL, THREAD360371159
SEAL, OIL 1 1/2 I.D. x 2 1/4 O.D. x 5/16 THICK300078158
SEAL, OIL 1 1/4 I.D. x 1 3/4 O.D. x 1/4 THICK300077157
SEAL, OIL 3/4 I.D. x 1 1/4 O.D. x 1/4 THICK300076156
PLATE, THRUST360364155
PIN, DOWEL300075254
REDUCER, −4 NPT / −2 NPT300074153
PLUG, PIPE −6 NPT HEX SOC HEADLESS300073152
PLUG, PIPE −4 NPT SQ HD300070251
REDUCER, −6 NPT / −2 NPT300069150
O−RING 1" O.D. x 1/8 THICK300068149
ITEM
QTY.
PART NO. DESCRIPTION
