RELAY PANEL ASSEMBLY
3203 SERIES
6-6.0.0
5/22/2003
FROM FROM END COLOR GAGE LENGTH TO END TO TO LABEL
CANNON PLUG - A SOLDER YELLOW 16 8.5 STRIP TERMINAL BLOCK - 15 N/A
TERMINAL BLOCK - 5 STRIP YELLOW 16 22
DEUTSCH CONTACT - 0462-201-
16141
DEUTSCH DT06-2S, PIN - 1, VALVE
BOOM UP COIL BOOM UP
DEUTSCH DT06-2S, PIN
- 2, VALVE BOOM UP
COIL
DEUTSCH CONTACT -
0462-201-16142 WHITE 16 20 SOLDER BLACK W IRE BOOM LIMIT CORD N/A
CANNON PLUG - B SOLDER GREEN 16 16 FEMALE SPADE HOIST RELAY - 1 HOIST UP
CANNON PLUG - C SOLDER ORANGE 16 8.5 STRIP TERMINAL BLOCK - 11 N/A
TERMINAL BLOCK - 1 STRIP ORANGE 16 24
DEUTSCH CONTACT - 0462-201-
16141
DEUTSCH DT06-2S, PIN - 1, VALVE
ROTATION CW COIL ROT CW
DEUTSCH DT06-2S, PIN
- 2, VALVE ROTATE
CW COIL
DEUTSCH CONTACT -
0462-201-16141 WHITE 16 22 1/4" RING TERMINAL GROUND N/A
CANNON PLUG - D SOLDER RED 16 14.5 #6-8 RING TERMINAL TOGGLE SW ITCH - 3 N/A
TOGGLE SWITCH - 2 #6-8 RING TERMINAL RED 16 4 STRIP TERMINAL BLOCK - 20
CANNON PLUG - E SOLDER WHITE/RED 16 8.5 STRIP TERMINAL BLOCK - 12 N/A
TERMINAL BLOCK - 2 STRIP W HITE/ RED 16 24.5
DEUTSCH CONTACT - 0462-201-
16141
DEUTSCH DT06-2S, PIN - 1, VALVE
ROTATION CCW COIL ROT CCW
DEUTSCH DT06-2S, PIN
- 2, VALVE ROTATE
CCW COIL
DEUTSCH CONTACT -
0462-201-16142 WHITE 16 22 1/4" RING TERMINAL GROUND N/A
CANNON PLUG - F SOLDER RED/BLACK 16 17 FEMALE SPADE HOIST RELAY - 4 HOIST DN
CANNON PLUG - G SOLDER BLACK 16 4 1/4" RING TERMINAL GROUND N/A
CANNON PLUG - H SOLDER GREEN/BLACK 16 8.5 STRIP TERMINAL BLOCK - 13 N/A
TERMINAL BLOCK - 3 STRIP GREEN/BLACK 16 22
DEUTSCH CONTACT - 0462-201-
16141
DEUTSCH DT06-2S, PIN - 1, VALVE
EXTEND COIL EXTEND
DEUTSCH DT06-2S, PIN
- 2, VALVE EXTEND
COIL
DEUTSCH CONTACT -
0462-201-16141 WHITE 16 22 FEMALE SPADE HOIST RELAY - 2 N/A
CANNON PLUG - J SOLDER WHITE/BLACK 16 20 FEMALE SPADE PUMP RELAY - 1 N/A
CANNON PLUG - K SOLDER BLUE 16 8.5 STRIP TERMINAL BLOCK - 16 N/A
TERMINAL BLOCK - 6 STRIP BLUE 16 22
DEUTSCH CONTACT - 0462-201-
16141
DEUTSCH DT06-2S, PIN - 1, VALVE
BOOM DOWN COIL BOOM DN
DEUTSCH DT06-2S, PIN
- 2, VALVE BOOM
DOWN COIL
DEUTSCH CONTACT -
0462-201-16141 WHITE 16 22 #6-8 RING TERMINAL HOIST RELAY - 2 N/A
CANNON PLUG - L SOLDER BLUE/W HITE 16 8.5 STRIP TERMINAL BLOCK - 17 N/A
CANNON PLUG - M SOLDER ORANGE/BLACK 16 8.5 STRIP TERMINAL BLOCK - 14 N/A
TERMINAL BLOCK - 4 STRIP ORANGE/BLACK 16 23
DEUTSCH CONTACT - 0462-201-
16141
DEUTSCH DT06-2S, PIN - 1, VALVE
RETRACT COIL RETRACT
DEUTSCH DT06-2S, PIN
- 2, VALVE RETRACT
COIL
DEUTSCH CONTACT -
0462-201-16141 WHITE 16 20 1/4" RING TERMINAL GROUND N/A
CANNON PLUG - N SOLDER ORANGE/RED 16 15
DEUTSCH CONTACT - 0460-202-
16141
DEUTSCH DT04-4P-L012, PIN - 4,
PENDANT PLUG, CAN L N/A
DEUTSCH DT04-4P-
L012, PIN - 1, PENDANT
PLUG, +
DEUTSCH CONTACT -
0460-202-16141 RED 16 5.5 STRIP TERMINAL BLOCK - 8 N/A
CANNON PLUG - P SOLDER RED/WHITE 16 8 FEMALE SPADE (BOSCH PLUG) BOSCH RELAY - 85 N/A
CANNON PLUG - T SOLDER BLACK/WHITE 16 12
DEUTSCH CONTACT - 0460-202-
16141
DEUTSCH DT04-2P, PIN - 1,
PROGRAM PIN PROGRAM PIN
CANNON PLUG - U SOLDER BLUE/RED 16 16 SOLDER
WHITE/RED WIRE (PRESSURE
SWITCH TO A2B) N/A
CANNON PLUG - V SOLDER GREEN/WHITE 16 16
DEUTSCH CONTACT - 0460-202-
16141
DEUTSCH DT04-4P-L012, PIN - 3,
PENDANT PLUG, CAN H N/A
DEUTSCH DT04-4P-
L012, PIN - 2, PENDANT
PLUG, -
DEUTSCH CONTACT -
0460-202-16141 BLACK 16 4.5 1/4" RING TERMINAL GROUND N/A
