TRANSMITTER / RECIEVER
SYNCHRONIZATION
8-8.0.0
05/22/2003
1. Power on the transmitter and receiver.
2. Locate the program plug on the crane. This will be the unused plug near where the
cord reel plugs into the wire harness.
3. Using a jumper wire, as shown below, connect the two contacts in the plug.
4. While the jumper is installed and the transmitter is unplugged from the pendant cable,
activate a function on the transmitter. Note: The crane must be electrically powered
but it is not necessary to supply hydraulic power to complete synchronization.
5. Remove the jumper wire.
Important: The jumper wire should not be left installed. Doing so could cause the
crane to be operated by another transmitter.
