auto maskin DCU 305 R3 User Manual

Page 18 (20)
Port P3
The DCU 305 R3 has a 9-pin D-SUB male connector at port P3, outlined
as follows:
Pin # Description
2 RxD
3 TxD
4 DTR
5 SG
7 RTS
8 CTS
Port P10:
The DCU 305 R3 has a 9-pin D-SUB male connector at port P10,
outlined as follows:
Pin # Description
2 CAN-L
7 CAN-H
Multidrop communication
Several DCU 305 R3 units may be connected together in what is known
as a multidrop network.
For this to work correctly, each of the connected units must have its
unique ID-number in the range 1-239. This is done using the parameter
program Rudolf.
Further, the multidrop net must be an RS-485 net. This means that RS-
232/RS-485 converter units, for instance the ICPCON RS232/RS485
unit, must be connected close to the communication port P3 of each DCU
305 R3 unit.
We recommend using a twisted pair cable with two pairs of at least 0.22
mm
2
, and capacity lower than 60pF/m.
Please contact your dealer or Auto-Maskin for correct dip setting and
cabling of these units in a network.
