Page 5 (20)
Technical Specifications
Part Value
Overall dimensions (1) 160 x 260 x 35 mm (H x W x D)
Cut-out dimensions 146 x 230 mm (H x W)
Supply voltage (2) 24V smoothed, (20 – 35V DC)
Power consumption (3) 500mA/12W @24V DC
Weight Control unit: 1250g
Protection level Front panel:
Back panel:
IP54
IP30
Ambient temperature During operation:
Storage:
0-70°C
-20-70°C
Air humidity During operation:
Storage:
<90%
Dry
Analog alarm latency Built-in channels:
Expansion card AK-6:
~ 1 sec
~ 5 sec
RK-66 relay rating
120VAC
24VDC
1A
1A
Notes
(1) The cables on the backpanel add to the overall depth.
(2) LCD backlight disappears if primary supply is below 18 volts, and reappears
when primary supply is above 20 volts.
(3) Display brightness full, 5 x 50% analogue inputs.
